Nitronic 50 (XM-19) Sheet ,Plate,coils Manufacturer in India

Nitronic 50 (XM-19) Sheet ,Plate,coils Manufacturer, Supplier and Exporter in India

Nitronic 50 (XM-19) Sheet ,Plate,coils, Nitronic 50 (XM-19) Sheet ,Plate,coils Manufacturer, Nitronic 50 (XM-19) Sheet ,Plate,coils Supplier and Exporter, Nitronic 50 (XM-19) Sheet ,Plate,coils Exporter

Sumer Metal Industries Private Limited is a reputed manufacturer, supplier, and exporter of high‑quality Nitronic 50 (UNS S20910 / ASTM XM‑19) in forms such as sheet, plate, and coils. The company sources or mills this nitrogen‑strengthened austenitic stainless steel in compliance with international standards including ASTM A240 for sheet/plate and ASTM A479 or A276 for bar and coil forms. Their global export footprint covers sectors like marine hardware, offshore oil & gas, petrochemical, heat exchanger, and cryogenic applications.

Nitronic 50 is a nitrogen‑strengthened austenitic stainless steel that delivers notably greater corrosion resistance than 316/316L stainless at approximately twice the yield strength. It remains non‑magnetic even when cold‑worked or at cryogenic temperatures. Commonly used in demanding environments—sea‑water pumps, valve hardware, springs, shafts, fasteners, heat exchanger components—the alloy is ideal when simultaneous strength and corrosion resistance are essential

Nitronic 50 (XM-19) Sheet ,Plate,coils

Sumer Metal Industries manufactures SS 904L Pipes in various forms, including seamless, welded, ERW, and fabricated pipes, in multiple sizes, thicknesses, and standards such as ASTM B677 and ASME SB677. The company supports custom requirements and exports these pipes to markets across the Middle East, Europe, Africa, and Asia, backed by secure packaging and timely delivery.

SS 904L (UNS N08904 / EN 1.4539) is a super austenitic stainless steel alloy developed for high resistance to aggressive corrosion environments, especially in conditions where standard 304 or 316 stainless steel would fail. These flanges offer superior resistance to sulfuric, phosphoric, and acetic acids, as well as chloride-induced stress corrosion cracking and pitting. The addition of copper and molybdenum enhances its acid resistance, making it a preferred material in applications where contamination must be avoided and long-term reliability is essential. Its non-magnetic nature and excellent weldability also add to its advantages in critical processing units..

Nitronic 50 (XM-19) Sheet ,Plate,coils Specifications

Property Specification
Material Name Nitronic® 50 (XM-19), UNS S20910
Standards ASTM A240, ASTM A276, ASTM A479, ASME SA240, ASME SA479
Product Forms Sheet, Plate, Coil
Thickness Range Sheets: 0.5 mm – 6 mm
Plates: 6 mm – 50 mm
Coils: 0.25 mm – 5 mm
Width Range Up to 1500 mm (standard); wider available on request
Length (Sheet/Plate) 2000 mm, 2500 mm, 3000 mm, custom lengths available
Finish Options 2B, BA, No.1, No.4, Matte, Bright Annealed, Polished
Tensile Strength (Min) 690 MPa (100 ksi) – Annealed condition
Yield Strength (0.2% offset) 380 MPa (55 ksi) – Annealed condition
Elongation (%) ≥35% (in 50 mm gauge length)
Hardness (Max) 293 HB (Annealed)
Density 7.9 g/cm³ (typical for austenitic stainless steels)
Melting Range 1370 – 1398°C
Corrosion Resistance Superior to 316L in chloride and marine environments
Magnetic Response Non-magnetic even after cold working
Heat Treatment Solution Annealed at ~1066°C (1950°F), followed by rapid cooling
Certification EN 10204 3.1 / 3.2, NACE MR0175, ISO 9001
Applications Marine, Pumps, Valves, Fasteners, Oil & Gas, Chemical, Cryogenic services

Chemical Composition of Nitronic 50 (XM-19) Sheet ,Plate,coils

Element Minimum (%) Maximum (%)
Chromium (Cr) 20.5 23.5
Nickel (Ni) 11.5 13.5
Manganese (Mn) 4.0 6.0
Molybdenum (Mo) 1.5 3.0
Silicon (Si) — 1.00
Nitrogen (N) 0.20 0.40
Carbon (C) — 0.06
Phosphorus (P) — 0.04
Sulfur (S) — 0.03
Vanadium (V) 0.10 0.30
Niobium (Cb) 0.10 0.30
Iron (Fe) Balance Balance

SS 904L is a super austenitic stainless steel with low carbon content and high levels of nickel, molybdenum, and copper, giving it outstanding resistance to sulfuric acid, chloride-induced pitting, and stress corrosion cracking. Sumer Metal’s 904L coils exhibit excellent formability, weldability, and durability in harsh and corrosive environments. These coils are available in hot rolled (HR) and cold rolled (CR) forms and are used in fabricating heat exchangers, tanks, piping systems, and structural components.

Mechanical Property of Nitronic 50 (XM-19) Sheet ,Plate,coils

Property Annealed Condition Cold-Worked / High-Strength Condition
Tensile Strength (min) 690 MPa (100 ksi) 860–1000 MPa (125–145 ksi)
Yield Strength (0.2% offset) 380 MPa (55 ksi) 585–690 MPa (85–100 ksi)
Elongation (in 50 mm) ≥ 35% ≥ 15%
Reduction of Area ≥ 55% ≥ 45%
Hardness (Brinell, max) ≤ 293 HB ~ 320–350 HB (approximate)
Modulus of Elasticity 195 GPa (28 x 10⁶ psi) 195 GPa
Poisson’s Ratio ~0.27 ~0.27
Density 7.9 g/cm³ 7.9 g/cm³
Melting Range 1370 – 1398°C (2500–2550°F) Same
Impact Toughness at -196°C > 75 J > 70 J
Magnetic Permeability < 1.005 Remains non-magnetic

Nitronic 50 (XM-19) Sheet ,Plate,coils Manufacturer - Types of Nitronic 50 (XM-19) Sheet ,Plate,coils

Nitronic 50 (XM-19) Sheet ,Plate,coils supplier in Mumbai India

Sheet
Plate supplier in Mumbai India

Plate

Coils supplier in Mumbai India

Coils

Applications & Uses

  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Sugar Industry.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Power Industry.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in ShipBuilding Industry.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Mechanical and Plant engineering.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Food, Beverage, and Dairy.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Oil and Gas Plant.
  • Nitronic 50 (XM-19) Sheet ,Plate,coils used in Process Instrumentation.
City we Supply Nitronic 50 (XM-19) Sheet ,Plate,coils:
Pune Mumbai Chennai Hyderabad Kolkata Bengaluru
Raipur Ahmedabad Jaipur Surat Salem Delhi
Bhubaneswar Tiruppur Sivakasi Jamnagar Thiruvananthapuram Rajahmundry
Bhiwandi Vijaywada Firozabad Bokaro Steel City Rajkot Bharuch
Panna Raipur Cochin Ludhiana Panipat Durgapur
Peenya Pimpri-Chinchwad Channapatna Kharagpur Nashik Bareilly
Varanasi Haldia Rourkela Bangalore Moradabad Indore
Patna Trivandrum Pithampur Dibrugarh Angul Gwalior
Coimbatore Kannur Nagpur Vadodara Rudrapur Bareilly
Agra Bhagalpur Thane Bhilai Pithampur Kanpur
Noida Bhopal Sri City Jamshedpur Hosdurg Lucknow

Countries we export Nitronic 50 (XM-19) Sheet ,Plate,coils worldwide - Sumer Metal Industries Private Limited

Nitronic 50 (XM-19) Sheet ,Plate,coils are Exported by Sumer Metal Industries Private Limited to Europe, Africa, Asia, the United Arab Emirates, and other continents. There are a variety of high-quality Nitronic 50 (XM-19) Sheet ,Plate,coils Suppliers all around the world who offer items with full certifications and short turnaround times. We can help you get the greatest quality Nitronic 50 (XM-19) Sheet ,Plate,coils from any Pipe manufacturer in the world at the best price.

Countries We Supply Welded Pipes
Saudi Arabia Oman Kuwait Netherlands Iran
Bahrain Qatar UAE Africa China
Nigeria Mexico Canada Venezuela United Kingdom
United States South Africa Malaysia Bangladesh Turkey
Singapore Sri Lanka Australia Brazil Germany
France Italy South Korea Poland Belgium
